Classic High Line Flat Fender Set with 6 inch Flare NO Inner Fender for Jeep TJ / LJ

The High Line Fenders are the latest cutting edge designed TJ fenders on the market. They provide room for bigger tires without having to add lift to your Jeep. Made from 3/16 inch laser cut steel they will take anything you can throw at them. The High Line fenders are loaded with some amazing features. Looking for the clearance of a high line fender but the most tire coverage then the 6 inch flare is the way to go.

Specifications

• 3/16 inch Laser cut and CNC formed steel plate
• 6 Inch Flare
• 3 inchs of additional clearance above the tire
• 2 3/4 inches of extra clearance behind the tire.
• Vented side plates provide custom look and venting for heat dissapation
• Raw Metal Must be painted.
• Inner Fender Not Included
• Fits 97-06 Wrangler TJ/LJ
• Includes Passenger & Driver Support Brackets
• Weight: 90lbs (approx.)


Notes:

• Your factory hood must be cut approximately 3 inches to fit fenders.
• Optional battery boxes are available for the Optima or Diehard series batteries.
• Hood latches will need to be relocated or hood pins installed.
• Your battery will be relocated and mounted forward.  Optional battery boxes are available for the Optima or Diehard series batteries are shown in the related products tab.
• You must either fabricate your own inner fenders or use the Motobilt MB1083-IF inner fenders with stock cut outs or the MB1083-IFB blank inner fenders for use with coil overs.

Product Components

Instructions

Note: These instructions cover BOTH outer and inner fender install. INNER FENDERS SOLD SEPARATELY.

Assembly Instructions
