Dana 30 Diff Cover

Shipping calculated at checkout.

The Motobilt Dana 30 HD steel diff cover has many features that separate it from others. The Dana 30 HD steel diff cover features a 3/8" thick steel ring that will keep the cover from pulling away from the housing when dragging over rocks. The Dana 30 HD steel diff cover also features the proven 1/4" thick steel plate design with an integrated 3/4" NPT fill plug. The fill plug on the Dana 30 HD steel diff cover allows for easy access, especially when a truss system is commonly used. The Dana 30 HD steel diff cover is welded both on the inside and outside of the cover to ensure maximum protection for superior strength for your front axle to protect your gears and lockers. The Dana 30 HD steel diff cover's design comes from over 14 years of diff cover testing and manufacturing experience. The diff cover ships bare steel and will need to be painted. We do not usually powder coat ours because the diff cover is going to take abuse from rocks. Spray paint works well so you can simply touch it up. The bolts and fill plug ship with the cover.

Will fit Jeep CJ, YJ, TJ, LJ, XJ, MJ, ZJ, JK & JKU.

Weight = 10lbs



  • 9/16 allen head - For the fill plug.
  • 12 point 5/16 socket and ratchet


  • Oil Fill: Use the amount of oil suggested by the manufacturer for your year, make and model. Do NOT fill to the top of the fill plug, unless this is the appropriate amount for your application.

Installation Instructions
